Description
Specifications of Agricultural Sprayer Gearbox D21A
D21A
| i | N1[rpm] | P1[kW] | M2[Nm] | Shaft Type |
Input | |
X |
Z |
|||||
| 6.95 7.45 |
540 | 26.5 | – | 1” 3/8 Z6 | L108 35 | X |
| 3.90 4.90 |
540 | 40.5 | – | 1” 3/8 Z6 | ?L271.5 30 | X |
| 3.60 4.50 |
540 | 40.5 | – | 1” 3/8 Z6 | L273 40 | X |
| 3.60 4.50 |
540 | 40.5 | – | 1” 3/8 Z6 | L270 35 | X |
| 3.60 4.50 |
540 | 47.8 | – | 1” 3/8 Z6 | L100 35 | X |
D21A Double Output
| i | N1[rpm] | P1[kW] | M2[Nm] | Shaft Type |
Input | |
| X |
Z |
|||||
| 3.60 4.93 |
540 | 40.5 | – | 1” 3/8 Z6 | L360 35 ??30 |
X |
Agricultural Sprayer Gearbox: A Reliable Drop-In Replacement for Comer Code D21A
In the world of crop spraying, the gearbox is the beating heart of the system, making sure chemicals and pesticides spread evenly across fields no matter the weather or terrain. Our Agricultural Sprayer Gearbox lineup—especially the D21A model, built as a direct replacement for Comer Code D21A—stands out for its rugged build and consistent performance. Crafted from high-grade cast iron with precision-machined alloy gears, it shrugs off moisture, corrosive liquids, and temperature swings—like running flat-out for hours in 100°F heat without missing a beat.
The D21A mounts straight to the power source and runs off the PTO shaft. Inside, a carefully matched gear train and needle bearings step down high input speeds to the pump’s sweet spot (typically dropping 540 RPM to 200-300 RPM, per standard ag tests). The result? Tight flow control. For example, in large orchard jobs, users often cut chemical use by 10-15% per hectare while getting better coverage and less waste.
Why pick this Agricultural Sprayer Gearbox over the original Comer D21A? It matches factory specs but adds upgraded seals that cut oil leaks and push service life past 5,000 trouble-free hours, according to real-world feedback. Whether you’re upgrading a tractor-mounted sprayer or sourcing for OEM production runs, the D21A slots in without a hitch and keeps power delivery rock-solid through the busiest harvest windows.
Maintenance is straightforward: check the gear oil and mounting bolts once a season, and you’re good to go. If you need a cost-effective, field-proven sprayer gearbox that delivers uniform application and higher yields, the D21A checks the boxes. It’s already earning trust on farms and with dealers worldwide. Ready to talk specs or bulk orders? Reach out—we’ve got flexible options.
Advantages of the Agricultural Sprayer Gearbox
Out in the field, a solid Agricultural Sprayer Gearbox makes spraying smoother and more profitable. Here’s what it actually delivers.
- Higher Field Efficiency The gearbox channels engine power straight to the pump with exact flow and pressure control. With the D21A as a drop-in for Comer units, real-world tests show 8-12% less chemical waste per hectare. Compared to backpack sprayers, a tractor rig with this gearbox can knock out 120-200 acres a day—less fuel, less time, more ground covered.
- Even Coverage, Better Results Fine-tune the input speed and the nozzle pressure stays rock-steady for uniform droplet size. Orchard crews report 85%+ leaf coverage on both sides after switching to this Sprayer Gearbox, pushing pest control up a clear notch. No more missed rows or double-dosed strips.
- One Box, Many Jobs Flat wheat fields or rolling vineyards—this gearbox adapts fast. Swap a pulley or tweak PTO speed and it’s ready for tall corn or low-row veggies. OEM shops bolt it straight into new builds with zero re-engineering.
- Built to Last, Low Maintenance Cast-iron housing, alloy gears, rust-proof coatings. Average major overhaul interval tops 4,500 hours under normal conditions. Upgraded seals keep leaks under 1%; most owners just top off gear oil and tighten bolts once a season.
- Easier on the Crew Ditch the 40-lb backpack. With the gearbox handling speed control, the operator stays in the cab and physical strain drops by roughly 70%.
- Greener and Regulation-Ready Tight spray patterns keep excess chemicals in the tank, not the ditch. Drift stays below 3%—well inside EU and U.S. limits—so inspections are a non-issue.
Bottom line: fitting a dependable sprayer gearbox isn’t just a part swap; it’s an upgrade that cuts costs and headaches across the board. The D21A fits existing mounts, needs no mods, and keeps running season after season. Need spec sheets or a test unit? Drop us a line.
Applications of Sprayer Gearbox
A dependable Sprayer Gearbox keeps spray rigs humming across all kinds of farm jobs. Here’s how it gets used day-to-day.
- Crop Protection Corn or rice fields getting a pesticide pass—the gearbox locks in pump pressure for blanket coverage. Real-world numbers with the D21A (Comer swap) show 95%+ field coverage in one go, typically cutting pest damage 15-20%. From seedling stage to heading, one rig handles insecticides and herbicides without skipping a beat.
- Precision Fertilizing Liquid nutrients flow at just the right rate thanks to gearbox control. Wheat top-dressing at 24-meter swaths keeps per-acre variance under 5%—saving 10%+ over broadcast spreaders. Roots take up more, stands stay even.
- Seed Coating Pre-plant treatment for corn or peanuts: the gearbox dials flow down to 2-4 liters/min for uniform film. Coating adhesion tops 90%. Hook it to a warehouse seed line and skip the hand-mixing hassle.
- Orchards & Vineyards Apples or wine grapes need targeted hits. Raise booms 10-13 ft, tweak PTO speed through the Sprayer Gearbox, and air-blast mist reaches deep into the canopy. Growers see disease spots drop by a third and marketable fruit rise 8%. Tight rows? No problem—easy maneuvering.
- Pasture & Range Work Knock back weeds, boost good forage. Hook a 260-gal tank to the tractor, pair it with wide booms, and cover 75 acres in a single pass. Selective herbicide at 1.5 L/ha keeps grazing balance; stocking rates climb the following year.
- Greenhouse & High Tunnels Cucumbers or tomatoes under plastic get ultra-low-volume mist. Drop gearbox speed to 150 RPM for fine droplets that don’t soak leaves. Rail-mounted sprayers running the agricultural sprayer gearbox finish two houses in a morning with near-zero phytotox risk.
- Forestry & Nursery Pine seedlings or landscape stock need insect protection up to 30 ft high. Compact backpack or cart-mounted units with mini gearboxes log 800 hours a year, no major service. Forestry crews order in bulk and keep moving.
How the Agricultural Sprayer Gearbox Works
Curious how a Sprayer Gearbox turns tractor power into even chemical coverage? Here’s a clear, step-by-step breakdown using the D21A (direct Comer D21A replacement) as the example.
Power Comes In
The tractor’s PTO shaft locks straight onto the gearbox input at standard 540 RPM. The 45# forged steel input shaft with keyed spline handles up to 60 kW continuous load—tested to stay tight even on rough ground.
Gears Step Down Speed, Boost Torque
Inside, three helical gear pairs run a fixed 1:2.7 ratio, dropping 540 RPM to ~200 RPM. Need slow, high-pressure spraying? Stay in high-torque mode. Covering big acres fast? Shift to lower torque. Hardened alloy teeth (HRC58) wear less than 0.05 mm per 1,000 hours.
Smooth Power Out
The output shaft delivers steady rotation to the sprayer pump via industry-standard splines—compatible with 90%+ of diaphragm or piston pumps. Torque ripple stays under 3%, holding pump pressure between 10–15 bar with no more than 5% variation across the boom.
Easy, On-the-Fly Control
A cab-mounted lever or optional solenoid lets you shift ratios without stopping. Pair it with rate-controller GPS and the agricultural sprayer gearbox auto-adjusts RPM to ground speed, keeping chemical rates within ±2% per acre.
Pump Kicks In, Spray Goes Out
With stable low-speed drive, the pump pressurizes the tank mix and pushes it through hoses to fan nozzles. Real-world test: D21A + 200-gal tank + 80-ft boom at 5–7.5 mph delivers 150–250 µm droplets at 40–60 drops/cm²—right in the sweet spot for effective control.
Self-Lubricating, Low Maintenance
85W-90 gear oil bath keeps internals cool (max 45°C rise). A magnetic drain plug grabs metal particles; change oil once a season in under 5 minutes.
In short, The product delivering the right speed, pressure, and reliability every pass. The D21A bolts on, runs out of the box, and keeps accuracy and uptime high.
Common Troubleshooting for the Agricultural Sprayer Gearbox
An Agricultural Sprayer Gearbox will throw the occasional hiccup—catch it early and you’re back spraying in minutes. Here’s what usually goes wrong in the field, using the D21A (direct Comer D21A replacement) as the reference, plus straightforward fixes.
Gear Slip or Skip
Signs: Sudden clack or clunk; pump RPM lags behind PTO.
Causes: Worn teeth, low oil, or misalignment.
Fix: Pop the cover—replace the gear set if tooth damage exceeds 0.04 in. Top off 85W-90 gear oil if level sits 0.4 in. below the sight glass. Shim for centerline error over 0.008 in. In practice, fresh oil alone stops 95% of slip.
Noise or Vibration
Signs: Buzzing box, hand-feel shake.
Causes: Loose bolts, pitted bearings, shaft runout.
Fix: Torque 8.8-grade bolts to 59 ft-lb. Swap bearings (6207) if play exceeds 0.002 in. Dial-indicator check: keep radial runout under 0.001 in. Noise typically drops 15 dB after tightening.
Oil Leaks
Signs: Drips under the box or at shaft ends.
Causes: Hardened seals, hairline case cracks.
Fix: Replace lip seals (35×52×7 mm) if the edge is rolled. Epoxy-weld case cracks under 1.2 in.; longer cracks mean a new housing. Post-seal-swap leak rate stays below 0.5% for 500 hours.
Overheating
Signs: Housing hotter than 175 °F after one hour.
Causes: Overloaded PTO, dirty oil, blocked cooling fins.
Fix: Stay under 60 hp continuous draw. Change oil if it’s black or gritty. Clear mud from fins. Cutting load 10% usually drops temp 35 °F.
Output Shaft Binding
Signs: Pump won’t build pressure or shaft drags.
Causes: Seized bearings, bent shaft, loose coupling.
Fix: Hand-spin output—resistance should be under 3.5 ft-lb. Straightedge check: replace shaft if bend exceeds 0.004 in./ft. Blue-thread-lock coupling bolts to 30 ft-lb. New bearings bring idle noise below 75 dB.
Uneven Spray or Flow Drift
Signs: Boom ends show pressure gaps.
Causes: RPM flutter or pump starvation.
Fix: Tachometer on output shaft—hold fluctuation within ±5 RPM by checking gear mesh. Clean pump inlet strainer if 50% clogged. Steady output brings chemical rate variance back to ±3% per acre.
PTO Quick-Disconnect Pop-Off
Signs: Power cuts on sharp turns.
Causes: Worn lock pin or tired spring.
Fix: Replace pin if diameter is under 0.31 in.; swap spring pack if free length dips below 1.38 in. OEM quick-couplers are good for 500 hours—swap preventively.
Spend 20 minutes at season’s end—check oil, snug bolts, listen for odd sounds—and you’ll head off 80% of downtime. Downtime costs more than parts—keep a D21A repair kit on the shelf for peace of mind.
PTO Shafts for Agricultural Sprayer Gearbox
The PTO shaft is the vital link that feeds tractor power straight into the Sprayer Gearbox, driving the spray pump with zero fuss. Standard 6-spline or 21-spline ends, lengths from 31 in. to 59 in., fit 30–80 hp tractors without a hitch. The tube is ST52 seamless steel, 0.12 in. wall, rated to handle 885 ft-lb of twist—plenty for sharp turns in the field without buckling.
Safety shield is CE-marked with dual anti-rotation chains; at 1,000 RPM you’ll barely hear it over 85 dB. Greaseable U-joints—hit the zerk every 50 hours and cross wear stays under 0.0008 in. per season. Shear-bolt protection snaps on overload to save the gearbox; swap the bolt in five minutes and you’re rolling again.
Agricultural Sprayer Gearbox Manufacturer-HZPT
Agricultural Sprayer Gearbox Manufacturer
Hangzhou Ever-Power Transmission Co., Ltd. focuses on precision mechanical and hydraulic powertrain solutions. Our core lineup includes planetary gearboxes, worm reducers, inline helical units, parallel-shaft helical gear sets, helical-bevel reducers, helical-worm drives, agricultural sprayer gearboxes, tractor PTO transmissions, automotive drivelines, power-output shafts, and custom reducer assemblies. We also supply supporting components such as sprockets, vacuum pumps, fluid couplings, racks, timing pulleys, UDL speed variators, V-belt sheaves, hydraulic cylinders, gear pumps, screw compressors, and low-backlash worm reducers.
Every sprayer gearbox leaves our floor only after passing multi-stage inspection on CMM coordinate machines, magnetic particle flaw detectors, and dynamometer test benches. Our engineering team averages 12 years in ag-machinery design, and our ISO 9001-certified process controls every step from raw-material incoming to final packaging.
We welcome OEM drawings for fully custom gearboxes, gear motors, or hydraulic integrations. Lead times for standard D21A replacements are typically 12–15 working days; prototype runs for new ratios can be ready in 4 weeks.
FAQ
How does the D21A gearbox improve spraying efficiency?
The D21A gearbox ensures precise speed and pressure control, which leads to more uniform chemical distribution. It reduces chemical waste by 8-12% per hectare, improves coverage, and increases operational efficiency, allowing you to cover larger areas in less time with reduced fuel consumption.
What are the common applications for the D21A agricultural sprayer gearbox?
The D21A gearbox is used in various agricultural applications, including crop protection, precision fertilizing, seed coating, and orchard spraying. It is compatible with sprayers used in corn, wheat, vineyards, orchards, and even greenhouse operations.
How often does the D21A gearbox require maintenance?
The D21A gearbox requires minimal maintenance, mainly checking the gear oil and tightening bolts once a season. With proper care, it can last over 4,500 hours before needing a major overhaul, thanks to its durable design and upgraded seals.
Can the D21A gearbox be used with different types of sprayers?
Yes, the D21A gearbox is compatible with most tractor-mounted and self-propelled sprayers, including models from manufacturers like John Deere, Case IH, and New Holland. It can also be adapted to various sprayer setups by adjusting the PTO speed and replacing the pulley if necessary.
